Cooler Master GX II 850W 80+ Gold Fully Modular PCIe 5.1 ATX 3.1 Power Supply Black

Sku: MPX-8503-AFAG-2EBAN

Availability: Out of Stock

Brand: Cooler Master

Category: Power Supplies

$262.90

850W ATX power supply featuring ATX 12V Ver. 3.0, 80 PLUS Gold efficiency, and a fully modular design. Equipped with a high-performance 120mm HDB fan, advanced safety protections (OPP, OVP, OTP, OCP, SCP, UVP), and a 12VHPWR connector for modern GPUs.

-
+

100% Guarantee Safe Checkout

Thumbnail 3

Description

Manufacture: Cooler Master | Model: MPX-8503-AFAG-2EBAN



The Cooler Master GX 850W power supply is a high-performance, fully modular PSU designed for demanding gaming and workstation setups. With an 80 PLUS Gold certification, it ensures over 90% efficiency at typical loads, reducing energy waste and enhancing system stability. Featuring a durable 120mm HDB fan running at 2500 RPM, it delivers efficient cooling with minimal noise. The unit supports the ATX 12V Ver. 3.0 standard and includes a 12VHPWR connector for next-generation graphics cards. With multiple safety protections and premium build quality, the GX 850W is an excellent choice for high-power systems requiring reliability and efficiency.



Key Features:



  • 850W Power Output for High-Performance Systems
  • 80 PLUS Gold Certified for ≥90% Energy Efficiency
  • Fully Modular Design for Optimized Cable Management
  • ATX 12V Ver. 3.0 Standard for Modern System Compatibility
  • 120mm HDB Fan with 2500 RPM for Superior Cooling
  • Active PFC for Stable Power Regulation
  • Comprehensive Safety Protections: OPP, OVP, OTP, OCP, SCP, UVP
  • Includes 12VHPWR Connector for High-End GPUs
  • Compact and Durable Build for Long-Term Reliability

ATX Version ATX 12V Ver. 3.0
PFC Active PFC
Input Voltage 100-240V
Input Current 10-5A
Input Frequency 50-60Hz
Dimensions (L x W x H) 160 x 150 x 86 mm
Fan Size 120mm
Fan Bearing HDB
Fan Speed 2500 RPM
Efficiency ≥90% @ Typical Load
80 PLUS Rating 80 PLUS Gold
ErP 2014 Lot 3 Yes
Operating Temperature 0-40°C
Power Good Signal 100 - 150 ms
Hold Up Time ≥16ms at 80% Load
MTBF >100,000 Hours
Protections OPP / OVP / OTP / OCP / SCP / UVP / Surge & Inrush Protection
Regulatory cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region's requests.)
ATX 24 Pin Connectors 1
EPS 4+4 Pin Connectors 1
EPS 8 Pin Connector 1
SATA Connectors 6
Peripheral 4 Pin Connectors 2
PCI-e 6+2 Pin Connectors 4
12VHPWR Connector 1
Series GX Series
80 Plus Efficiency Gold
Modular Fully Modular
Category Above 750W
Form Factor ATX
Watts 850W
