CISCO Ip67 Ie 8 10/100 Poe 2 Ge With 1588 & IE-2000-8T67P-G-E

SKU : IE-2000-8T67P-G-E
Brand : Cisco
Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered
Cisco IE-2000-8T67P-G-E Industrial Ethernet, RAM 256 megabyte, Flash Memory 64 megabyte, Capacity IGMP groups: 255, VLANs supported: 1005, Wall-mountable, Ports-8, Slots 1 (total) / 1 (free) x SD Memory Card, Interface 8 x 100Base-TX M12 PoE+, 1 x console M12, 2 x 1000Base-T M12 uplink, MTBF 374,052 Hours. The Cisco Industrial Ethernet (IE) 2000 IP67 Series is Cisco's first ruggedized switching platform that complies with the most demanding IP67 industrial standards. It also provides everythi
Ask a question about this product
$5,060.00

Estimated Shipping

Delivery when available

Pay what you see.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Cisco | Model # IE-2000-8T67P-G-E



The Cisco Industrial Ethernet (IE) 2000 IP67 Series is Cisco's first ruggedized switching platform that complies with the most demanding IP67 industrial standards. It also provides everything you've come to expect from the global leader in Internet Protocol (IP) networking: easy integration with the rest of your network, reliability, rock-solid performance, and world-class support.



Cisco IOS Software features extend all the way to the factory floor, rail yard, or other industrial site, even in the harshest environments. So you can finally fulfill the promise of network convergence-across both information technology (IT) and operations technology (OT) environments-with one supplier.



Features:

  • Extended Enterprise capability with Cisco DNA Center management
  • Easy deployment, with zero-touch discovery using DHCP and an express setup with a swappable SD flash card
  • A user-friendly device manager, the Cisco Network Assistant, a Cisco Prime interface, and third-party management solutions
  • Resilience and fast network recovery with Flex Links, fast convergence with Cisco Resilient Ethernet Protocol



Overview:

  • Performance: Forwarding performance (64-byte packet size): 6.5 Mpps
  • Capacity: IGMP groups: 255, VLANs supported: 1005
  • Type: Switch
  • Form Factor: Wall-mountable
  • Ports Qty: 8



Manufacturer Warranty: 01 Year Limited Warranty

Technical Specifications

Brand Cisco
Product Line Cisco Industrial Ethernet
Model 2000 IP67 Series
Packaged Quantity 1
RAM Installed Size 256 megabyte
Flash Memory Installed Size 64 megabyte
Performance Forwarding performance (64-byte packet size): 6.5 Mpps
Capacity IGMP groups: 255, VLANs supported: 1005
Type Switch
Subcategory Network hubs and switches
Subtype Fast Ethernet
Form Factor wall-mountable
Ports Qty 8
Routing Protocol OSPF, RIP, BGP, Static IPv6 routing, Static IPv4 routing
MAC Address Table Size 8K entries
Manageable Yes
Remote Management Protocol SNMP 3, SNMP 2, Telnet, RMON, SSH, SNMP 1
Power Over Ethernet (PoE) PoE+
Features Pv6 support, Spanning Tree Protocol (STP) support, MAC address filtering, Virtual Route Forwarding-Lite (VRF-Lite), DiffServ support, VLAN support, IGMP snooping, DHCP relay, IGMP filtering, Multicast Storm Control, DHCP server, Rapid Spanning Tree Protocol (RSTP) support, Precision Time Protocol (PTP), Syslog support, Class of Service (CoS), NAT support, LLDP support, Unicast Storm Control, Quality of Service (QoS), PROFINET v2, Cisco Fast EtherChannel, Multiple Spanning Tree Protocol (MSTP) support, MAC Address Notification, DHCP snooping, BOOTP support, Remote Switch Port Analyzer (RSPAN), ARP support, Uni-Directional Link Detection (UDLD), Broadcast Storm Control, Port Security, Dynamic ARP Inspection (DAI), Trivial File Transfer Protocol (TFTP) support
Compliant Standards IEEE 802.3af, IEEE 1588v2, IEEE 802.1Q, IEEE 802.3, IEEE 802.1ab (LLDP), IEEE 802.1s, IEEE 802.1D, IEEE 802.1w, IEEE 802.3x, IEEE 802.1x, IEEE 802.1p, IEEE 802.3u, IEEE 802.3at, IEEE 802.3ab
Qty 8
Type 10/100 (PoE+)
Qty 2
Type 10/100/1000
Expansion Slots 1 (total) / 1 (free) x SD Memory Card
Interfaces 8 x 100Base-TX M12 PoE+, 1 x console M12, 2 x 1000Base-T M12 uplink
Type Cisco IOS LAN Enhanced
Power Consumption Operational 73 watt
Color Category White
Authentication Method Secure Shell (SSH), RADIUS, TACACS+
MTBF 374,052 Hours
Compliant Standards UL 60950-1, EN 61000-4-6, NEMA TS-2, EN 50121-3-2, CISPR 22 Class A, IEC 60068-2-64, IEC 60068-2-30, IEC 60068-2-14, EN 61000-4-2, EN 61000-4-29, EN 61000-6-4, EN 61000-6-1, EN 61000-4-4, IEC 60068-2-27, EN 60950-1, EN50155, EN 55011, EN 61000-4-5, EN 61000-4-3, EN55024, EN 61000-6-2, EN 61000-4-8, EN 60945, IEC 60068-2-31, EN55022 Class A, IEC 60068-2-32, EN 50121-4, ICES-003 Class A, IEC 60068-2-6, VCCI Class A, IEC 60068-2-52, IP67, EN 61131-2, NEMA Type 4, EN 61326, CISPR 24, EN 61000-4-9, EN 61000-4-10, CISPR 11 class A, UL 508, BSMI CNS 13438 Class A, IEC 60950-1, IEC 61850-3, CSA 22.2 No. 142
Width 9.3 inch
Depth 3.9 inch
Height 9.5 inch
Weight 7.19 lbs
Min Storage Temperature -40 degree Fahrenheit
Max Storage Temperature 185 degree Fahrenheit
Humidity Range Operating 5 - 95% (non-condensing)
