CISCO Ie 4 10/1002 Fe IE-2000-4T-L Managed

SKU : IE-2000-4T-L
Brand : Cisco
Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse
Cisco IE-2000-4T-L Performance Forwarding performance (64-byte packet size): 6.5 Mpps, Gigabit Ethernet, Ports 6, Expansion Slots1 (total) / 1 (free) x SD Memory Card, Interface 6 x 100Base-TX RJ-45, MTBF 374,052 Hours. The Cisco Industrial Ethernet 2000 (IE 2000) series is a range of compact, industrially ruggedized access switches. IE 2000 series provides customers with ease of use, secure access, and industry leading convergence using Cisco Resilient Ethernet Protocol (REP).
Ask a question about this product
$1,481.00

Estimated Shipping

Pay what you see.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Cisco | Model # IE-2000-4T-L



The Cisco Industrial Ethernet 2000 (IE 2000) series is a range of compact, industrially ruggedized access switches. IE 2000 series provides customers with ease of use, secure access, and industry leading convergence using Cisco Resilient Ethernet Protocol (REP).



Multiple industries such as automotive, oil and gas, mining, transportation, and energy companies are all increasingly requiring IP based networks in their production areas. The IE 2000 additions have been designed to support access layer connectivity and to meet the increasing needs for security, voice, and video traffic across industrial networks.



Features:

  • Two gigabit combo ports: SFP (100 Mbps and 1 Gbps) or RJ45 uplink
  • Industrial Power over Ethernet (PoE) solution
  • Swappable SD flash card and mini-USB connector
  • Industrial environmental compliance and certifications



Overview:

  • Form Factor: DIN rail mountable
  • Ports Qty: 6
  • Routing Protocol: Static IPv4 routing, IGMP
  • MAC Address Table Size: 8K entries
  • Manageable: Yes
  • Remote Management Protocol: SNMP 3, SSH



Manufacturer Warranty: 01 Year Limited Warranty

Technical Specifications

Brand Cisco
Product Line Cisco Industrial Ethernet
Model 2000 Series
Packaged Quantity 1
RAM Installed Size 256 megabyte, 256 megabyte
Flash Memory Installed Size 64 megabyte, 64 megabyte
Performance Forwarding performance (64-byte packet size): 6.5 Mpps
Capacity Virtual interfaces (VLANs): 255
Type Switch
Subcategory Network hubs and switches
Subtype Gigabit Ethernet
Form Factor DIN rail mountable
Ports Qty 6
MAC Address Table Size 8K entries
Manageable Yes
Remote Management Protocol SNMP 3, SSH
Features Unicast Storm Control, RADIUS support, Layer 2 switching, Broadcast Storm Control, Spanning Tree Protocol (STP) support, Full duplex capability, Rapid Spanning Tree Protocol (RSTP) support, Multicast Storm Control
Compliant Standards IEEE 802.3ad (LACP), IEEE 802.1p, IEEE 802.3, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.3u, IEEE 802.1D, IEEE 802.3x, IEEE 802.1s, IEEE 802.1w
Ports Qty 6
Type 10/100
Expansion Slots 1 (total) / 1 (free) x SD Memory Card
Interfaces 6 x 100Base-TX RJ-45
Type Cisco IOS LAN Lite
Rack Mounting Kit Optional
Authentication Method TACACS+, Secure Shell (SSH), RADIUS
MTBF 374,052 Hours
Compliant Standards EN 61000-6-1, IEC 60529 IP30, ICES-003 Class A, FCC Part 15 A, EN 61000-4-3, RoHS, EN 61000-4-8, EN 61000-4-4, EN 61000-6-4, EN 61000-4-9, EN 61000-4-29, EN55022 Class A, EN 61131-2, EN 61000-4-6, IEC 60068-2-14, CISPR 24, IEC 60068-2-27, EN 61326-1, CISPR 22 Class A, IEC 60068-2-6, IEC 60950-1, FCC CFR47 Part 15, UL 60950-1, C-Tick, IEC 61000-4-11, VCCI Class A ITE, EN 61000-4-2, CSA 22.2 No. 142, CISPR 11, KCC, UL 508, EN 61000-4-5, EN 60950-1, IEC 60068-2-30
Width 2.9 inch
Depth 4.5 inch
Height 5 inch
Weight 2.45 lbs
Min Storage Temperature -40 degree Fahrenheit
Max Storage Temperature 185 degree Fahrenheit
Humidity Range Operating 5 - 95% (non-condensing)
