Manufacture # Canon | Model # E14
ACTi's 10MP Cube Camera with Basic WDR and 3.6mm Interchangeable Lens is a high-resolution surveillance camera for indoor installations. It's ONVIF-compliant and can be used with compatible NVRs for recording, or simply with ACTi software and MicroSD cards. In either scenario, a connection to a network is required. When connected to an NVR, the NVR provides Power-over-Ethernet to the camera, and when working with ACTi software, the network connection provides Power-over-Ethernet.
Overview:
Manufacturer Warranty: 01 Year Limited Warranty
| Image Sensor | 1/2.3" Progressive Scan CMOS |
| Minimum Illumination | Color: 0.1 lux at F1.8 (30 IRE, 2400K) |
| Electronic Shutter | 1/5 - 1/2,000 sec (manual mode); 1/5 - 1/10,000 sec (auto mode) |
| TV Lines | 1450 |
| S/N Ratio | 52 dB |
| Lens | Interchangeable lens; fixed focal, f3.6 mm / F1.8 |
| Lens Mount | CS mount |
| Iris | Fixed iris |
| Focus | Manual focus |
| Horizontal Viewing Angle | 99° |
| Multi-Streaming | Simultaneous dual streams based on two configurations |
| Video Compression | H.264 HP, MJPEG |
| Bit Rate | 28 Kbps - 6 Mbps (per stream) |
| Bit Rate Mode | Constant, Variable |
| Audio Compression | 8 kHz, Mono, PCM, 16 bit encoding; G.711 |
| Audio Input | Built-in microphone |
| Audio Output | 3.5 mm phone jack |
| Network Protocol | TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour |
| Ethernet Port | 1x RJ-45, Ethernet (10/100 Base-T) |
| Security | IP address filtering, HTTPs encryption, password protected user levels, anonymous login, IEEE802.1X network access control |
| Alarm Trigger | Video motion detection (3 regions) |
| Local Storage | MicroSDHC/MicroSDXC memory card slot (card not included) |
| Power Source | PoE Class 2 (IEEE802.3af) |
| Power Consumption | 3.84 W |
| Color | White |
| Approvals | CE (EN 55022 Class B, EN 55024), FCC (Part15 Subpart B Class B) |
| Starting Temperature | 14 to 113°F (-10 to 45°C) |
| Operating Temperature | 14 to 113°F (-10 to 45°C) |
| Operating Humidity | 10 - 85% RH |
| Dimensions | 3.8 x 3.8 x 1.8" (9.6 x 9.6 x 4.5 cm) |
| Weight | 0.8 lb (376 g) |
| Frame Rate / Resolution | 6 fps @ 3648 x 2736, 6 fps @ 3648 x 2160, 6 fps @ 2592 x 1944, 6 fps @ 2048 x 1536, 30 fps @ 1920 x 1080, 30 fps @ 1280 x 720, 30 fps @ 640 x 480, 15 fps @ 320 x 240 |
