Sku: VS82H-AT
Brand: ATEN
Category: Network Accessories
Availability: On Order
On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.
Shipping Calculator
Find
We Accept
Manufacture: Aten | Model: VS82H-AT
Display True 4K content to 2 displays at once.
Connect to any HDMI video source and start sharing. No drivers required.
Small in size with robust high-quality aluminum housing.
Enhanced compatibility from source to display for the right resolution every time.
| EDID Settings | PORT-1 & Default |
| LEDs | |
| Status | HDMI Output x 2 (Blue) Power Input x 1 (Blue) |
| Video Input | |
| Interfaces | 1 x HDMI Type A Female (Black) |
| Impedance | 100 Ω |
| Max. Distance | 30cm at 4K@60Hz (4:4:4) |
| Video Output | |
| Interfaces | 2 x HDMI Type A Female (Black) |
| Impedance | 100 Ω |
| Max. Distance | 5m at 4K@60Hz (4:4:4) |
| Video | |
| Max. Data Rate | 18 Gbps (6 Gbps Per Lane) |
| Max. Pixel Clock | 600 MHz |
| Compliance | HDMI 2.0 (3D, Deep Color, 4K); HDCP 2.2 Compatible |
| Max. Resolution | Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) |
| Power Consumption | DC 5V:1.35W:4.6BTU/h Note: ? The measurement in Watts indicates the typical power consumption of the device with no external loading. ? The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. |
| Connectors | |
| USB Port | Micro-USB to USB cable (50cm) X 1 Firmware upgrade & power source |
| Environmental | |
| Operating Temperature | 0-40 °C |
| Storage Temperature | -20 - 60 °C |
| Humidity | 0 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal (aluminum) |
| Weight | 0.09 kg ( 0.2 lb ) |
| Dimensions (L x W x H) | 8.80 x 6.00 x 1.50 cm (3.46 x 2.36 x 0.59 in.) |
| Carton Lot | 40 pcs |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
