ATEN Usb To 4 Port Rs232 Serial UC2324-AT

Sku: UC2324-AT

Availability: In Stock

Brand: ATEN

Category: USB Adaptors

$124.30

The ATEN USB-to-Serial RS-232 Hub offers a simple and cost-effective solution for adding up to four RS-232 serial ports to USB-enabled devices like computers, laptops, and handhelds. Ideal for communication and automation applications, it supports up to 115.2 Kbps data transfer rate per port and features hot-swapping, plug-and-play functionality, and 16KV ESD protection for reliable performance.

100% Guarantee Safe Checkout

Description

Manufacture: Aten | Model: UC2324-AT

The ATEN USB-to-Serial RS-232 Hub provides an external plug-and-play RS-232 serial connection for computers, notebooks, laptops, and handheld computing devices that support the USB specification. It provides a quick, simple, and cost-effective solution and is ideal for various communication and automation applications.

ATEN provides 4 models in this series: 2/4-Port USB-to-Serial RS-232 Hub; 2/4-Port USB-to-Serial RS-422/485 Hub

Package Contents

1x USB-to-Serial Hub
1x USB Cable
1x Installation Disk
1x User Instructions

Easy way to add 4 RS-232 serial ports
Fully compliant with USB 1.1; USB 2.0 compatible
Supports RS-232 serial interface
Supports automatic handshake mode
Up to 115.2 Kbps data transfer rate for each serial port
Dual data buffers for each upstream and downstream data transfer
No IRQ, DMA, I/O address resources required
Supports hot-swapping and plug-and-play
Built-in 16KV ESD protection
Supports both bus power and external power
Works with cellular phones, PDAs, digital cameras, modems and ISDN terminal adapters
OS support - Windows 2000/2003/XP/NT

Device Connections	4
Connectors
USB Port	1 x USB Type B Female (White)
Power	1 x DC Jack
Serial	4 x DB-9 Male (Black)
LEDs
Ports	4 (Green)
Power	1 (Orange)
Data Rate	115.2 Kbps (max.)
USB Specification	USB 1.1 Compliant; USB 2.0 Compatible
Power Mode	Bus Powered; use of Power Adapter is optional
Power Consumption	DC5V:0.4W:2BTU/h Note: ? The measurement in Watts indicates the typical power consumption of the device with no external loading. ? The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Environmental
Operating Temperature	0–50?C
Storage Temperature	-20–60?C
Humidity	0–80% RH, Non-condensing
Physical Properties
Housing	Metal
Weight	0.32 kg ( 0.7 lb )
Dimensions (L x W x H)	12.50 x 8.00 x 2.50 cm (4.92 x 3.15 x 0.98 in.)
Note	For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
