Sku: TUF-GAMING-B650EM-E-WIFI
Brand: Asus
Category: AMD Boards
Availability: In Stock
Ships in 1-2 days.
Pickup from Seven Hills in 1-2 days.
Shipping Calculator
Find
Product Type: Micro-ATX Motherboard, Model: TUF GAMING B650EM-E WIFI, CPU Socket: AM5, Chipset: AMD B650, RAM: 4x DDR5 DIMM (Max 256GB, 8000+ MT/s OC), PCIe: 1x PCIe 5.0 x16 (Primary), Storage: 3x M.2 (1x PCIe 5.0), 4x SATA 6Gb/s, Network: 2.5G Ethernet, Wi-Fi 6, Bluetooth 5.2, Audio: Realtek 7.1 HD
We Accept
Manufacture # ASUS | Model # TUF-GAMING-B650EM-E-WIFI
ASUS TUF GAMING B650M-E WIFI takes all the essential elements of the latest AMD Ryzen™ Desktop Processors and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive cooling system, this motherboard goes beyond expectations with rock-solid and stable performance for marathon gaming. TUF GAMING motherboards also undergo rigorous endurance testing to ensure that they can handle conditions where others may fail. Aesthetically, this model incorporates rugged off-black and geometric design elements to reflect the dependability and stability that defines the TUF GAMING series. This platform delivers the power and connectivity that advanced AI PC applications demand.
Key Features:
Manufacturer Warranty: 01 Years Limited Warranty
| Product Family | ASUS TUF Gaming B650 |
| Model Number | TUF GAMING B650EM-E WIFI |
| Form Factor | Micro-ATX (9.6 inch x 9.6 inch / 24.4 cm x 24.4 cm) |
| CPU Socket | AMD Socket AM5 |
| Supported CPU | AMD Ryzen™ 9000, 8000, and 7000 Series Desktop Processors |
| Chipset | AMD B650 |
| Memory Slots | 4x DIMM, Dual Channel |
| Memory Type | DDR5, ECC and Non-ECC Un-buffered Memory |
| Max Memory | 256GB |
| Max Memory Speed (OC) | Up to 8000+ MT/s (OC) |
| Primary PCIe x16 Slot (CPU) | 1x PCIe 5.0 x16 (for Ryzen 9000 & 7000 Series) / PCIe 4.0 x16 (for Ryzen 8000 Series) |
| Other PCIe Slots (Chipset) | 1x PCIe 4.0 x1 slot |
| M.2 Slots (Total) | 3x M.2 slots |
| Primary M.2 Slot Speed | M.2_1 (PCIe 5.0 x4 Mode) - Type 2280 |
| Secondary M.2 Slot Speed | M.2_2 (PCIe 4.0 x4 Mode) - Type 2280 |
| Third M.2 Slot Speed | M.2_3 (PCIe 4.0 x4 Mode) - Type 2242/2260/2280 |
| SATA Ports | 4x SATA 6Gb/s ports |
| Networking (Wired) | Realtek 2.5Gb Ethernet (TUF LANGuard) |
| Networking (Wireless) | Wi-Fi 6 (802.11ax), Bluetooth v5.2 |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC |
| Video Outputs (Rear I/O) | 2x DisplayPort, 1x HDMI™ Port |
| Rear USB Ports | 2x USB 10Gbps (1x Type-A + 1x Type-C®), 2x USB 5Gbps (Type-A), 4x USB 2.0 (Type-A) |
| Front Panel USB Connectors | 1x USB 5Gbps connector (supports USB Type-C®), 1x USB 5Gbps header (supports 2 Type-A), 2x USB 2.0 headers (supports 4 Type-A) |
| Power Stages | 8(80A)+2(80A)+1(80A) Power Stages |
| Special Features | BIOS FlashBack™ Button, SafeSlot, SafeDIMM, M.2 Q-Latch, Two-Way AI Noise Cancelation |
